TREND CNC ROTARY CARVER and VCARVE Pro Software Package

Trend CNC Mini Machine
CNC Rotary Carver Machine 6.35mm 240V - UK sale only
Ref: CNC/ROT/1

NEW, BOXED and UNUSED
ONE ONLY AT THIS PRICE

Key Features:

• Desktop cylinder CNC router is for small woodworking priojects, ornament and tiny furniture.
• Maximum component diameter of 200mm with working length of 300mm.
• Brushless 150 watt DS motor for low noise and longer life expectancy with belt-driven head.
• Desktop model with micro switch fully guarded safety dust cover for safe operation making it ideal for education.
• Use on hardwoods, softwoods, exotic woods and many synthetic materials such as acrylic, and ABS, foam, modelling wax, styrene and epoxy board.
• Endless possibilities in what you can create: use images from digital photos, CAD drawings, computer generated art programs, scanned images and more.
• Ideal for education, small workshop and home use.
• Includes a simple, straight forward common platform software package.
• Works with any PC computer running Windows XP up to Windows 10.
• For UK sale only.

• 1 x USB 2.0 cable
• 1 x Bravo Edit software disk
• 1 x USB controller
• 1 x Collet extension kit with 4mm and 1/4" collet
• 1 x Conical radius carving cutter R0.5mm STC
• 1 x End mill cutter two flute 3.96mm STC
• 1 x Spike chuck
• 1 x Four jaw chuck
• 1 x Hex key 2.5mm A/F
• 1 x Instruction manual

• For UK sale only.
• Voltage: 240 volt
• Table load weight max.: 5 kg
• Max. working length:300 mm
• Max. component dia.: 200 mm
• Fixed thimble clamp dia.: 200 mm
• Jaw chuck inner clamp dia.: 2 mm to 16 mm
• Jaw chuck inner clamp dia: 25 mm to 60 mm
• Jaw chuck outer clamp dia.:22 mm to 55 mm
• Max. engraving speed: 2500 mm/min
• Min. engraving speed: 40 mm/min
• Repositional accuracy: 0.1 mm
• Resolution software: 0.02 mm (0.001 inch)
• Power supply input: 220-240V
• Power supply output; DC 24V 6.5A
• Spindle motor: 150 watt DC
• Power consumption: 2.0A
• Collet capacity max.: 1/4-inch
• Operating noise level: 39.6 dB(A) standby
• No loading operation noise: <66 dB(A)
• Spindle speed: 0-17000 rpm
• Interface: USB 2.0
• System requirements; PC running Windows XP up to Windows 10
• Machine size depth: 366 mm
• Machine size width ;635 mm
• Machine size height ;610 mm
• Weight: 42 kg
